Specifications

Focal Length

20-1100mm

Focal Length (2X)

40-2200mm

Zoom Ratio

55X

Format

1 inch

Maximum Aperture

1: 3.0

Clear Aperture (Front)

7.64 inches (194.0 mm)

Clear Aperture (Rear)

0.79 inches (20.0 mm)

Mount

C-Mount with internal camera support

Back Focal Distance

28.04 (in air)

Focus Range

2.4 meters to infinity

Control

Serial (Ethernet Optional)

Calibration

Corrected Zoom and Focus Positions

Processor

PC-104

Housing Construction

Welded Aluminum

Pressurization

3.0 psi

Power – Voltage

28VDC

Power – Current

4 amps maximum

Dimensions

38Lx12Hx12W inches

Weight

137 pounds
