Photo-Sonics Metric Zoom Lens:
12.5mm - 1500mm f/3.8 - f/7.6 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Specifications |
Focal Length
|
12.5 - 750mm
f/3.8 |
Focal Length
(2X) |
25-1500mm
f/7.6 |
Zoom Ratio
|
60X |
Format |
½ inch |
Maximum
Aperture |
1: 3.8
|
Mount
|
C-Mount with
internal camera support |
Focus Range
|
5 meters to
infinity |
Control
|
Serial
(Ethernet Optional) |
Calibration
|
Corrected
Zoom and Focus Positions |
Processor
|
PC-104
|
Housing
Construction |
Welded
Aluminum |
Pressurization |
3.0 psi |
Power –
Voltage |
28VDC
|
Power –
Current |
4 amps
maximum |
Dimensions |
25.875L x
7.250 H x 7.250W inches |
Weight |
45 pounds
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
